Download N84PBH Specification
What's in the Box
1XNVR
1XUSB Mouse
1XPower Cable
1XHDD Date Cable
1XHDD Power Cable
1XScrew bag
1X1m Network cable
1X1.8 m HDMI cable
1XUser Manual For NVR
Video & Audio
| Decoding FormatH.265+/H.265/H.264+/H.264 |
IP Video Input32 Channel, up to 12MP resolution |
| Video OutputHDMI up to 4K, VGA up to 1080p |
Video output modeHDMI/VGA simultaneous output |
| Audio Input/Output1/1 RCA |
Incoming/outgoing Bandwidth160/80 Mbps |
| Max Recording ResolutionUp to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) |
Max Playback ResolutionUp to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) |
| Max Playback Channel16CH |
Remote Connection64 |
Decoding Capability1-ch@12 MP/1-ch@8 MP/3-ch@4 MP/6-ch@1080p
The length or width of camera resolution (each track) cannot exceed 4096 pixels. |
Network protocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP,
UPnP™, HTTP, HTTPS |
| HDD4 SATA Interface |
Alarm Input/Output16/4 |
| Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
HDD CapacityUp to 8 TB Capacity for Each HDD(32 TB total) |
| Serial Interface1 RS-485 (Half-Duplex), 1 RS-232 |
USBFront Panel: 2X USB 2.0; Rear Panel: 1X USB 2.0 |
| Decoding FormatH.265+/H.265/H.264+/H.264 |
| IP Video Input32 Channel, up to 12MP resolution |
| Video OutputHDMI up to 4K, VGA up to 1080p |
| Video output modeHDMI/VGA simultaneous output |
| Audio Input/Output1/1 RCA |
| Incoming/outgoing Bandwidth160/80 Mbps |
| Max Recording ResolutionUp to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) |
| Max Playback ResolutionUp to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) |
| Max Playback Channel16CH |
| Remote Connection64 |
Decoding Capability1-ch@12 MP/1-ch@8 MP/3-ch@4 MP/6-ch@1080p
The length or width of camera resolution (each track) cannot exceed 4096 pixels. |
Network protocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP,
UPnP™, HTTP, HTTPS |
| HDD4 SATA Interface |
| Alarm Input/Output16/4 |
| Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| HDD CapacityUp to 8 TB Capacity for Each HDD(32 TB total) |
| Serial Interface1 RS-485 (Half-Duplex), 1 RS-232 |
| USBFront Panel: 2X USB 2.0; Rear Panel: 1X USB 2.0 |
General
| Operating Power100-240V AC |
Power Consumption≤ 15 W(without HDD and PoE off) |
| Working Temperature14 °F — 131 °F/-10 °C — +55 °C |
Dimensions (W X H X D)440 × 397 × 75 mm ( 17.3"× 15.6" × 3.0") |
| Weight (Without Hard Disk)≤ 11 lbs. (5 kg) |
|
| Operating Power100-240V AC |
| Power Consumption≤ 15 W(without HDD and PoE off) |
| Working Temperature14 °F — 131 °F/-10 °C — +55 °C |
| Dimensions (W X H X D)440 × 397 × 75 mm ( 17.3"× 15.6" × 3.0") |
| Weight (Without Hard Disk)≤ 11 lbs. (5 kg) |
